Lenco 15058-001 XDS Short Extreme Duty Actuator 12V 2-1/4" Stroke

The Lenco 101 XDS Short Extreme Duty Actuator is designed for OEM-specific kits and limited space applications where a compact, powerful electric actuator is essential. With a 2-1/4" stroke and overall length of just 10-7/8" (tip to tip), this is the shortest actuator Lenco manufactures, making it ideal for tight installation spaces on boats, RVs, and marine trim tab systems.

Advanced Design Features:

• Newly implemented Anti Extrusion Ring (AXR) seal stabilization system for enhanced durability
• Strengthened top cap and mounting clevis design for improved reliability
• Improved pressure-tight Torx screws prevent loosening under vibration
• Integrated wiper seal at actuator base keeps contaminants out
• Molded-in brass thrust bearing design reduces friction and wear
• Thicker and stronger motor housing wall for increased longevity
• Enhanced O-ring design provides more consistent sealing
• Over-molded cable construction creates a stronger, tighter seal
• Upper mounting bracket with gland seal for superior water resistance

Performance Specifications:

• Lenco's ballscrew design delivers twice the power of typical hydraulic systems with greater reliability
• High-torque motor generates 500 pounds of push force
• Waterproof "Plug & Play" Deutsch connectors eliminate water intrusion risks
• Constructed from high-impact, glass fiber-filled, UV-resistant nylon material
• 316 super buff stainless steel tubing resists corrosion in harsh marine environments
• 12-volt DC operation
• Includes 3/8" mounting hardware and 6-foot cable

Instant response electric actuation provides precise control for trim tabs, hatches, and other marine/RV applications where space is at a premium.
