Blue Sea Systems 7476 C-Series Flat Rocker Circuit Breaker 200A

The Blue Sea Systems 7476 is a single-pole, 200-amp magnetic hydraulic circuit breaker designed for reliable overcurrent protection in marine DC electrical systems. Part of the C-Series flat rocker line, this breaker features a low-profile design ideal for space-conscious panel installations.

Key Features:

• Magnetic hydraulic trip-free design cannot be held in the "ON" position during fault conditions
• Flat rocker actuator helps prevent accidental switching or snagging
• Color-coded actuator provides clear visual indication of "OFF" position
• Rated for 80 volts DC maximum operating voltage
• UL 1077 recognized and meets ABYC standards for marine circuit protection
• 10,000 rated switch cycles at full amperage and voltage

Specifications:

• Amperage Rating: 200A
• Pole Configuration: Single Pole
• Maximum Voltage: 80V DC
• Circuit Breaker Type: Magnetic Hydraulic, Trip-Free
• Terminal Type: Stud terminals

Blue Sea Systems C-Series circuit breakers provide dependable protection for high-current applications including inverters, windlasses, thrusters, and main distribution panels. The trip-free mechanism ensures the breaker will automatically open during overload conditions regardless of actuator position, providing critical safety protection for marine electrical systems.
