Blue Sea Systems 1202 AC Circuit Breaker Panel 120V 6 Position with 30A Main

The Blue Sea Systems 1202 Panel 360 delivers custom breaker panel aesthetics and functionality with off-the-shelf convenience. This vertical AC circuit breaker panel combines the modern styling and clean flat rocker switches of Blue Sea's modular 360 series with a pre-configured layout designed for common marine AC electrical applications.

Built on the same proven modular platform as Blue Sea's custom panels, this panel features a pre-installed 30A double-pole main breaker and six 15A single-pole branch circuit breakers, providing an ideal solution for basic 120V AC systems with room for future expansion. Each square label position is backlit for excellent visibility in low-light or nighttime conditions, while integrated LED indicators clearly show when each breaker is in the ON position.

Key Features:

• Pre-installed 30A AC main double-pole breaker for primary overcurrent protection
• Six 15A single-pole breakers for individual AC branch circuits
• Backlit square label positions for low-light visibility
• LED indicator lights clearly show breaker ON position
• Includes basic label kit with 30 square labels for circuit identification
• Modern flat rocker switch design with clean, professional appearance
• IP67 rated for below-deck marine installations
• CE approved for international standards compliance
• Backed by Blue Sea Systems lifetime warranty

Technical Specifications:

• Voltage Rating: 120V AC
• Main Breaker: 30A double-pole
• Branch Breakers: Six 15A single-pole
• Total Positions: 7 (1 main + 6 branch)
• Protection Rating: IP67 (below deck use)
• Dimensions: 7.75" H × 4.875" W × 3" D

This panel offers an excellent solution for new electrical system installations or upgrading existing panels, providing the sophisticated look and functionality of a custom-built panel without the lead time or complexity of configuring individual components.
