Blue Sea Systems 7035 25A Panel Mount Circuit Breaker

The Blue Sea Systems 7035 is a 25-amp thermal circuit breaker designed for marine DC electrical systems. This panel-mount circuit breaker combines switching and circuit protection into a single, space-saving device, making it ideal for boats, RVs, and other 12-48V DC applications.

Key Features:

• Type III switchable design with manual reset and trip-free operation prevents holding breaker "ON" during fault conditions
• Thermally responsive bi-metal blade provides reliable overcurrent protection
• Ignition protected components meet SAE J1171 requirements for safe installation on gasoline-powered vessels
• Waterproof construction withstands harsh marine environments
• Self-trimming thermoset polyester case eliminates need for mounting panels or trim bezels
• Round case design allows easy installation with standard hole saw
• Recessed mounting holes provide clean, professional appearance
• Robust 5/16-inch terminal studs with large clearance accept heavy gauge wire lugs and provide high torque connections
• Large, easy-to-operate lever with vertical/horizontal orientation clearly indicates trip status
• Clear single-lever operation for intuitive control

Specifications:

• Amperage Rating: 25 Amps
• Voltage Rating: 48 Volts DC Maximum
• Interrupt Rating: 5,000A @ 12V DC, 3,000A @ 24V DC, 1,500A @ 42V DC
• Operating Temperature Range: -13°F to 180°F (-25°C to +82°C)
• Case Material: Thermoset Polyester

This circuit breaker is ideal for protecting electrical circuits in marine, RV, and other DC power applications where reliable overcurrent protection and manual switching control are required.
