Blue Sea Systems 8379 A-Series Toggle 20-Position DC Circuit Breaker Panel with 100A Main

The Blue Sea Systems 8379 is a traditional DC circuit breaker panel featuring 20 positions with a 100A main breaker, designed to meet the reliability standards that marine electricians have trusted for years. This pre-wired aluminum panel provides comprehensive circuit protection and switching for 12V or 24V DC electrical systems in boats and marine applications.

Key Features:

• 20-position panel with C-Series 100A single pole main breaker for system protection
• Pre-installed 15A A-Series toggle breakers with additional open positions for customization
• Magnetic-hydraulic delay trip mechanism prevents nuisance tripping from motor start-up surges
• Trip-free design prevents breakers from being held ON during fault conditions
• Green LED indicators show breaker status at a glance
• Pre-installed backlit labels for easy identification in low-light conditions
• Pre-wired with positive, negative, and grounding bus bars for simplified installation
• Compatible with A-Series breakers rated from 2.5A to 50A for tailored circuit protection
• Includes digital multimeter with capability to monitor up to three battery banks
• Includes label set with 30 common DC circuit designations

Specifications:

• Nominal Voltage: 12V DC or 24V DC
• Maximum Amperage: 100A
• Panel Dimensions: 14 3/4" W × 7 1/2" H × 4" D
• Traditional aluminum plate construction
• Lifetime warranty

This panel combines robust circuit protection with the flexibility to expand and customize your electrical system as your needs grow. The industry-standard aluminum construction ensures compatibility with existing Blue Sea Systems installations.
