Blue Sea Systems 2135 25A Push Button Circuit Breaker

The Blue Sea Systems 2135 is a 25-amp thermal circuit breaker designed for marine DC electrical systems. This compact, panel-mount breaker features push-button reset operation and screw terminal connections, making it ideal for branch circuit protection on boats and RVs.

Key Features:

• 25-amp capacity with thermal trip protection for 12V/24V DC systems up to 32V
• Push-to-reset operation with trip-free design that cannot be held "ON" during fault conditions
• Ignition protected construction safe for gasoline-powered vessels
• Compact design enables high-density circuit protection configurations
• #8 screw terminals with 6 in-lb torque specification
• Panel mount with 3/8-27 UNS threading
• Compatible with optional waterproof boot for wet environment protection
• High interrupt capacity: 3000A at 14.7V / 2500A at 28V

Specifications:

• Amperage Rating: 25A
• Maximum Voltage: 32V DC
• Operating Temperature Range: -10°C to 60°C
• Weight: 0.09 lbs (0.04 kg)
• Terminal Torque: 6 in-lb (0.68 Nm)

This circuit breaker can be used for branch circuit protection or 24-hour circuit protection, and is incorporated into Blue Sea Systems WeatherDeck Waterproof Panels, Dual Battery Bank Distribution Panels, and 360 Distribution Panels.
