SeaSense 50031290 3 Gang Toggle Switch Panel with 12V Outlet

The SeaSense 50031290 is a marine-grade 3-gang toggle switch panel featuring an integrated 12V power outlet, designed specifically for boats and marine applications. This versatile switch panel combines reliable electrical control with convenient accessory power in a compact, weather-resistant housing.

Key Features:

• Three full 20-amp toggle switches with 15-amp fuse protection for safe circuit management
• Waterproof 12V power socket rated for 16 amps, ideal for charging devices or powering accessories
• Innovative wave-pattern faceplate design adds style while providing durability
• Reinforced corners prevent stress cracking from vibration and impact
• Water-resistant fuse holders with two fuses per circuit (one installed, one backup)
• Includes sealing gasket for watertight installation and weather protection
• Complete installation kit with mounting screws, gasket, and circuit label set

Specifications:

• Overall dimensions: 4-1/4" L x 3-3/4" W
• Required cutout: 3-3/8" L x 3-1/2" W
• Switch rating: 20 amps per circuit
• Fuse rating: 15 amps
• Power socket rating: 16 amps at 12V DC

This panel provides essential electrical distribution for running lights, bilge pumps, electronics, and other onboard systems. The included gasket and water-resistant construction make it suitable for exposed marine environments where moisture protection is critical.
