Awlgrip D3400G 545 Low VOC Epoxy Primer Converter - 1 Gallon

The Awlgrip D3400G is the Low VOC Converter (Part B) for the Awlgrip 545 Anti-Corrosive Epoxy Primer system — one of the marine industry's most trusted two-component epoxy primers. Designed to be mixed 1:1 by volume with a 545 Epoxy Primer Base, this converter activates the system to create a high-performance sealing primer ideal for preparing surfaces before the application of Awlgrip and Awlcraft 2000 topcoats.

Key Features:

• Low VOC formula — converter VOC: 353 g/lt (2.95 lbs/gal)
• Two-component epoxy primer system with outstanding corrosion and adhesion properties
• Seals filler primers and fairing work before topcoat application
• Suitable for use both above and below the waterline
• Compatible with steel, aluminum, wood, and fiberglass substrates
• Can be applied by spray, brush, or roller
• Simple 1:1 mix ratio (by volume) with 545 Epoxy Primer Base
• Fast overcoat times — minimum recoat window of 2–4 hours at 77°F/50% RH
• Maximum recoat window of 24 hours without sanding
• Recommended dry film thickness: 2–3 mils (50–75 microns)
• Sold in 1-gallon container

Once mixed, the 545 system may be overcoated with Awlgrip/Awlcraft 2000 Topcoats, 545 Epoxy Primer, High Build Epoxy Primer, Awl-Quik Sanding Surfacer, and Ultra-Build Epoxy Primer. For spray application, reduce up to 25% with T0167 or T0163 reducer. For brush or roller application, reduce 5–10% with T0031. In temperatures below 75°F, Cold Cure Accelerator M3066 may be used to maintain proper dry and cure times.

Cross-Reference Part Numbers: D3400/1GLUS | UPC: 841006002793
