Lippert Components V000301901 3500 lb 4-Inch Drop Trailer Axle 88-Inch Hub Face

The Lippert Components V000301901 is a 3,500 lb. capacity, 4-inch drop trailer axle with an 88-inch hub-face-to-hub-face length, designed as a direct replacement or upgrade axle for travel trailers, utility trailers, and campers.

Built on a 2-3/8-inch diameter, 3/16-inch wall round tube, this axle beam delivers the structural rigidity needed to handle the rated load with confidence. The 4-inch drop spindle design lowers the trailer frame relative to the axle centerline, helping maintain a lower center of gravity for improved towing stability.

Key Features:

• Load Capacity: 3,500 lbs.
• Hub Face Width: 88 inches
• Spindle Drop: 4-inch drop
• Axle Tube: 2-3/8" diameter x 3/16" wall round steel tubing
• Spring Seat Configuration: Underslung (springs mount below axle)
• Camber: Manufactured with a slight upward arch — must be installed with arch facing up
• Brake Compatibility: Compatible with drum or disc brake flanges (brakes not included)
• Suitable for travel trailers, campers, utility trailers, and boat trailers

Lippert Components is one of the largest axle manufacturers in North America, producing over 3,500 trailer axles per day for OEM and aftermarket applications. The V000301901 is engineered to Lippert's exacting standards for durability, alignment, and long-term performance on the road.
