Coleman-Mach 8330D735 Heat Ready Air Distribution Box Lateral Ducted RV Ceiling Assembly

The Coleman-Mach 8330D735 air distribution box with control board is a standard lateral ducted heat-ready ceiling assembly designed for use with a 12-volt DC wall thermostat (sold separately). This professional-grade ceiling assembly provides efficient air distribution for RV air conditioning systems.

Key Features:

• Heat strip ready - Electric Heat Kit (#62763) can be added to the ceiling assembly for enhanced climate control
• Integrated control board for reliable operation
• Standard lateral ducted design for optimal airflow distribution
• 12 Volt control voltage with 120 Volt rating
• FCC certified for safety and reliability
• White finish for clean, professional appearance

Compatibility:

Compatible with Coleman Mach 48203C9665 Series Roughneck, 48204 Series Mach 15, 48203 Series Mach 3 Plus, 48207 Series Mach I, 48208 Series Mach III Power Saver, Mach 8 Rooftop, and Mach 8 CUB Rooftop air conditioners.

Important Note:

The control box does not provide 12VDC for the thermostat - this must be supplied by the application. This ceiling assembly is not compatible with wall thermostats that are integrated into the unit; it requires a separate 12V DC wall thermostat for operation.
