Viega 91700 MegaPress 316 Stainless Steel 90 Degree Elbow 3/4 Inch Press FKM

The Viega MegaPress 316 FKM 3/4" 90 Degree Elbow delivers fast, reliable press connections for stainless steel piping systems without the need for welding, threading, or soldering. Engineered with premium 316 stainless steel construction, this elbow provides superior corrosion resistance for demanding applications including hydronic systems, compressed air, industrial gases, marine environments, and fire protection installations.

This press fitting features Smart Connect Technology and is designed for use with Schedule 5 through Schedule 40 stainless steel pipe. The FKM (fluoroelastomer) sealing element provides exceptional chemical resistance and temperature performance, making it ideal for applications involving oils, fuels, and aggressive chemicals where standard EPDM seals may not be suitable.

Key Features:

• 316 stainless steel body with NSF-61 potable water rating
• FKM sealing element for superior chemical and temperature resistance
• Compatible with Schedule 5 to Schedule 40 stainless steel pipe
• 420 stainless steel grip ring and 304 stainless steel separator ring
• Press connection eliminates hot work and reduces installation time
• Temperature range: 14°F to 284°F
• Pressure rating: 200 PSI
• Center-to-end dimension: 1.32 inches
• End-to-end length: 2.52 inches

Viega MegaPress fittings meet rigorous industry standards including ASTM A312, ANSI/CAN/UL 213, NFPA 13/13D/13R, and USCG approval. Installation requires Viega pressing tools with appropriate jaw sets for secure, leak-free connections. The press connection method significantly reduces labor costs and system downtime compared to traditional joining methods.
