Bob's Machine 100-408000 8" Fixed Setback Bracket for Outboard Motors

The Bob's Machine 100-408000 is an 8" fixed setback bracket for outboard motors, sometimes called a setback jack plate. It moves the motor back from the transom into cleaner water. This improves propeller efficiency and reduces prop slippage.

Key Features:

• 8" setback that repositions the motor rearward
• 1.5" of built-in lift with two mounting hole options for different engine heights
• 5/8" thick 6061 T6 aircraft-grade aluminum construction
• Designed for motors with the standard BIA bolt pattern, so the old transom holes do not need to be plugged and re-glassed
• Same industrial design and appearance as Bob's Machine hydraulic jack plates

Moving the motor back reduces drag and gives the boat more bow lift, which helps give a drier ride. Installation is straightforward. Remove the motor, mount the bracket in the transom's existing holes, then re-mount the motor on the bracket.
