The Lectrotab XKASAL12X24 is a professional-grade electric trim tab system designed for boats 28 to 48 feet in length. This complete kit includes 12" x 24" stainless steel trim tabs with integrated Automatic Leveling Control (ALC-1) for enhanced stability and fuel efficiency.
Premium Stainless Steel Construction:
Fabricated from heavy-duty 12-gauge 304 stainless steel, these trim tabs feature a continuous rolled and pinned hinge design that eliminates welding for superior strength and reliability. The upper ram seal location is protected from damage caused by fouled rams or barnacle growth, ensuring long-term performance in harsh marine environments.
Advanced Electric Actuator Technology:
Unlike hydraulic systems, these maintenance-free electric actuators are completely sealed in non-metallic, corrosion-resistant housings with no components required inside the boat. Each actuator delivers up to 1000 lbs of push force with a 2.25" stroke length and features an internal brake system that prevents unwanted tab movement when underway or backing down. The internal pressure equalization system and quiet operation make this system ideal for any vessel.
Automatic Leveling Control (ALC-1):
The included ALC-1 controller automatically adjusts your trim tabs to maintain optimal boat attitude, correcting both side-to-side roll and fore-to-aft pitch in real time. This provides a more comfortable ride, improves handling, and enhances fuel economy without constant manual adjustment.
Key Features:
- 12" x 24" trim tabs constructed from 12-gauge 304 stainless steel
- Continuous rolled and pinned hinge eliminates welded joints
- Electric actuators tested to 1000 lbs push force
- 2.25" stroke length with 23-foot actuator cables
- No hydraulic fluid to leak or maintain
- Non-metallic external housing resists corrosion and UV damage
- Internal brake prevents tab drift when underway
- Automatic leveling control for hands-free boat trim
- 12V DC operation
- All components are externally mounted for easy installation
Technical Specifications:
- Trim Tab Dimensions: 12" x 24" (30 x 61 cm)
- Recommended Boat Length: 28' to 48' (8.5 to 14.5 m)
- Material: 12-gauge, 304 stainless steel
- Actuator Voltage: 12V DC
- Actuator Stroke: 2.25" (57 mm)
- Actuator Cable Length: 23' (7 m)
- Actuator Vertical Height: 11.875" (302 mm)
- Control Dimensions: 3.15" x 3.07" (80 x 77 mm)
- Control Cutout: 2" diameter (50 mm)
- Control Operating Voltage: 12V or 24V DC
Complete Kit Includes:
- Two (2) 12" x 24" stainless steel trim tabs
- Two (2) electric actuators with 23' cables
- One (1) ALC-1 Automatic Leveling Control
- Installation hardware and instruction manual
This kit provides everything needed for a complete trim tab installation on single or twin engine boats, delivering professional performance with minimal maintenance requirements.
