Samlex DC-2000-KIT-XL 200A Inverter Installation Kit with Extended Cables

The Samlex DC-2000-KIT-XL is a complete inverter installation kit designed to provide a safe and reliable connection between your power inverter and battery bank. This kit is ideal for automotive, RV, marine, and renewable energy applications where extended cable length is required.

Kit Includes:

• Two 15-foot AWG #2 heavy-duty cables (one positive, one negative)
• 200A marine-rated battery fuse (MRBF series) with replaceable fuse
• Fuse assembly with clamping fixture
• All necessary mounting hardware including tie wraps, cable clamps, and screws

Key Features:

• Industrial-grade cables with annealed and tinned copper conductors for maximum flexibility and corrosion resistance
• Ethylene Propylene Rubber (EPR) insulation rated for 600V with superior resistance to abrasion, oils, acids, and heat
• Temperature rating from -50°C to 105°C (-58°F to 221°F)
• Pre-crimped copper ring terminals on both cable ends with 0.41-inch holes for 3/8-inch studs
• Suitable for 12V inverters from 1000-1700 watts and 24V inverters from 2000-3400 watts
• Marine-rated fuse provides weatherproof short-circuit protection

The extended 15-foot cable length provides additional flexibility for installations where the inverter must be mounted at a greater distance from the battery bank. All components meet ISO Standard 10133 specifications and are designed for safe, plug-and-play installation.
