ASA Electronics VOS719WPLD3B Voyager Wired Backup Camera System 7-Inch Monitor 3-Camera Kit

The ASA Electronics VOS719WPLD3B is a complete wired backup camera system designed for RVs, trucks, and heavy-duty vehicles requiring maximum visibility and safety. This comprehensive kit includes a professional-grade 7-inch QuadView monitor and three specialized cameras to provide complete coverage around your vehicle.

Complete System Includes:

• One VOM719WP 7-inch color TFT LCD monitor with QuadView capability
• One VCMS172B rear-mount backup camera with IR LED night vision
• One VCMS50RGP right side-marker camera
• One VCMS50LGP left side-marker camera
• One VOSHD4MNT 4-inch monitor mount
• Proprietary cabling for complete installation

Monitor Features:

• 7-inch digital wide-format color TFT LCD display with 800x450 resolution
• Supports up to 4 cameras with 6 triggers including single image, split-screen, and QuadView display modes
• DC auto source for switching triggers with turn signal compatibility
• Manual day/night display brightness controls with backlit control buttons
• Heavy-duty waterproof construction rated to withstand 4G continuous vibration
• AMPS mounting provisions with removable sun visor included
• Built-in speaker for audio monitoring
• 500 nit brightness and 500:1 contrast ratio for clear viewing in all conditions
• 16:9 aspect ratio with 60° top, 70° bottom, 75° left, 75° right viewing angles
• NTSC and PAL video signal compatible

Rear Camera Specifications (VCMS172B):

• High-performance 1/3-inch CMOS sensor with mirrored image orientation
• 600 TV line resolution with 0 Lux sensitivity for exceptional low-light performance
• 125° diagonal viewing angle (85° horizontal, 67° vertical)
• 12 LEDs for IR low-light assistance and night vision
• Built-in microphone for audio monitoring
• Waterproof and corrosion-resistant construction

Side Camera Specifications (VCMS50RGP/VCMS50LGP):

• High-performance 1/4-inch CMOS sensor with normal image orientation
• 380 TV line resolution with 0.5 Lux sensitivity
• 78° diagonal viewing angle (65° horizontal, 49° vertical)
• IR low-light assistance for visibility in dark conditions
• Aluminum housing with injected plastic body
• Waterproof and corrosion-resistant design

All cameras and monitor operate on 12-volt DC power and are NTSC video signal compatible. This professional-grade system is ideal for RVs, motorhomes, commercial trucks, buses, and any large vehicle requiring enhanced visibility for safe maneuvering and parking.
