Ezy-Glide 870-1050 Ezy-Stik III Mechanical Stick Steering System 10.5 ft Cable

The Ezy-Glide 870-1050 is an Ezy-Stik III Model 870 mechanical stick steering system, a side-mount helm with a 10.5-foot cable. It is a complete helm-and-cable steering system for boats. The Model 870 has a quicker turning ratio than the Ezy-Stik II, so it responds faster and needs less travel from lock to lock.

Key Features:

• Model 870 Ezy-Stik III stick steering with a 10.5-foot cable
• Total lever movement of 44.8 inches (161 degrees)
• Steering ratio of 5.0/1
• Housing about 7-1/2" x 7-1/2"
• 16" lever
• Rated for outboard engines up to 70 hp and jet drives up to 90 hp
• Designed to be mounted toward the port side
• Meets or exceeds NMMA/ABYC/BIA standards for the marine industry

Ezy-Glide notes that 4-stroke engines send more negative torque feedback to the operator. For a 4-stroke engine over 40 hp, it suggests the Ezy-Stik II Model 840 instead of the Model 870. Ezy-Glide recommends 80 Below Action Lube for lubrication.
