The Pacer Performance TAE2-14R-10 closed-end tinned lug provides a reliable, waterproof electrical connection for marine and automotive applications. Designed for 2 AWG stranded copper wire with a 1/4" stud size, this 10-pack of premium lugs features seamless construction with no exposed seams, making them ideal for harsh environments where corrosion resistance is critical.
Premium Construction for Maximum Durability:
Each lug is manufactured from seamless tubes of 99.9% electrolytic tough pitch copper (CDA-110) for superior conductivity. The tin-plated finish provides excellent corrosion resistance, while the closed-end design allows for fully waterproof connections when paired with epoxy-lined heat shrink tubing. The larger pad area ensures better electrical contact, and the controlled flare design allows easy cable insertion during installation.
Key Features:
- Tin-plated seamless copper construction prevents corrosion in marine environments
- No exposed seams for enhanced water resistance
- Rated for 600V applications
- Made from 99.9% copper for maximum conductivity
- Larger pad area provides superior electrical contact
- Cable size and stud hole clearly stamped on pad for easy identification
- Can be crimped or soldered for flexible installation
- Tight barrel-to-pad transition maximizes usable barrel length
- Designed specifically for stranded copper wire
Certifications & Compliance:
- E.T.P. (Electrolytic Tough Pitch) CDA-110 copper
- ASTM-B-152 copper rated at 100% conductivity
- UL & CSA Approved
- RoHS Compliant
- Exceeds SAE Conductivity Standards J163 & J1811
Technical Specifications:
- Wire Size: 2 AWG
- Stud Size: 1/4"
- Overall Length: 1.625"
- Width: 0.609"
- Clearance: 0.406"
- Voltage Rating: 600V
- Quantity: 10 pieces per pack
Installation:
Strip wire to the proper length, slide the lug over the exposed conductor until insulation meets the lug edge, then crimp using the appropriate crimping tool. For waterproof applications, cover the connection with epoxy-lined heat shrink tubing to fully encapsulate the connection and protect against moisture intrusion.
