B&G 000-15224-001 Zeus S 12 Inch Chartplotter Fishfinder with C-MAP Charts

The B&G Zeus S 12 is an advanced chartplotter and fishfinder system designed specifically for sailing enthusiasts, including cruisers, racers, and both monohull and multihull sailors. This intuitive marine navigation system features a 12-inch SolarMAX high-definition IPS touchscreen display with extreme viewing angles that remains viewable even through polarized lenses, making it ideal for bright sunlight conditions on the water.

Advanced Sailing Features:

• Unique Sailing Modes with customizable dashboards for cruising and racing situations
• Enhanced SailSteer, Laylines, and StartLine tools for competitive racing
• Chart-based Start Line tool with automatic distance capture and race timer countdown
• Wind history heat map showing true wind direction shifts over time
• Real-time estimated sailing time and distance calculations to any cursor position
• Internal GPS with sail-specific filtering and 10Hz position updates

Navigation and Mapping:

• Includes next-generation C-MAP DISCOVER X charts for North America with daily updates
• Compatible with C-MAP REVEAL X cartography for enhanced detail
• Quad-core microprocessors for seamless operation of instruments, radar, sonar, and charting
• Fastest-ever auto-routing with tide and current projections
• C-MAP powered Safety Alerts to guard against grounding and hazards
• Display resolution: 1280 x 800 pixels

Connectivity and Integration:

• Built-in Wi-Fi, Ethernet, and NMEA 2000 networking capability
• Full integration with Simrad radar, autopilot systems, instruments, and sensors
• Compatible with B&G App for trip planning, route management, and waypoint syncing
• Seamless integration with Triton Edge sailing processor
• GLONASS, Galileo, Beidou, and QZSS constellation support for worldwide positioning
• IP Video support for onboard cameras

Technical Specifications:

• Built-in 1 kW echosounder (transducer not included)
• IPX7 waterproof rating
• Supply voltage: 10-17 VDC
• Maximum current draw: 2.5 amps
• Includes U-bracket mounting hardware

The Zeus S features an intuitive Setup Wizard and helpful feature tips to guide users through configuration and operation. With its combination of powerful sailing tools, comprehensive chart coverage, and easy integration capabilities, the Zeus S 12 serves as the ideal centerpiece for a complete sailing navigation system.
