Peterson 850R-1 Rectangular LED Rear Stop, Turn & Tail Light with Hardwired Leads

The Peterson 850R-1 is a rectangular LED rear stop, turn, and tail light designed for commercial trucks, trailers, and heavy-duty vehicles. Combining three critical rear-lighting functions into a single compact unit, this light delivers long-lasting LED performance with a rated service life of 100,000 hours.

Key Features:

• 11-diode LED array with superior optics for bright, uniform illumination
• Hardwired 11.8" (300mm) stripped leads — no plug connector required, reducing connection points for improved reliability
• Multi-volt operation — compatible with both 12V and 24V electrical systems (9–32V operating range)
• IP67-rated sealed lens and housing for complete dust and water immersion protection
• DOT & ECE dual-certified — meets FMVSS 108 (USA) and ECE (European) standards in horizontal or vertical mounting positions
• Fits standard 139mm x 91mm grommet hole with 19mm corner radii
• Also compatible with surface-mount cluster pod assemblies (850-09 series)
• Grommet accommodates panel material up to 6mm thick
• 3-wire design — stop/turn/tail functions with ground through third wire

The 850R-1 ships with hardwired, stripped wire leads (11.8"/300mm). For a version with a PL3 plug, see the Peterson 850R-1P. Matching amber turn signal and white back-up lights are available separately. The light can also be integrated into a pre-assembled multi-light modular unit (850-092/850-093).
