Furuno GP3-400-183-06 6M NMEA 0183 Cable Assembly for GP340 GNSS Receiver

The Furuno GP3-400-183-06 is a 6-meter (19.7 ft) NMEA 0183 cable assembly designed specifically for use with the Furuno GP340 GNSS receiver. This optional cable allows the GP340 to output NMEA 0183 sentences instead of the standard NMEA 2000 connection, providing compatibility with older marine electronics and navigation systems.

Key Features:

• 6-meter proprietary cable length provides flexible installation options
• NMEA 0183 output with white and blue twisted pair configuration
• Fixed 38.4k baud rate for reliable data transmission
• Compatible with NavNet 1, NavNet VX2, and other NMEA 0183 systems
• Direct replacement for standard NMEA 2000 cable (only one cable type can be connected at a time)
• Proprietary 9-pin connector on GP340 receiver end

This cable assembly is ideal for integrating the high-performance GP340 GNSS receiver with legacy marine navigation equipment, chart plotters, autopilots, and fish finders that require NMEA 0183 input. The GP340 receiver features a powerful 75-channel GNSS core with support for GPS, GLONASS, Galileo, QZSS, and Beidou satellite systems, delivering position accuracy within 3 meters and a 10Hz update rate.

Important Note: The GP340 can output either NMEA 2000 or NMEA 0183 data, but not simultaneously. Only one cable type (NMEA 2000 or NMEA 0183) can be connected at a time.
