Pollak 52-271 6-Gang Terminal Block with Independent Feed

The Pollak 52-271 is a 6-gang terminal block with independent feeds, designed to provide a clean, organized, and centralized wiring connection point for 12V DC electrical systems. Ideal for truck, trailer, marine, RV, and industrial wiring applications, this compact terminal block simplifies complex multi-circuit installations while maintaining reliable, secure connections.

Key Features:

• 6-Gang Configuration: Six independent feed terminals allow separate circuit connections in a single, space-saving block
• UL & CSA Rated: Rated at 20A, 12V DC with a 300V DC voltage rating for safety and compliance
• Wide Wire Acceptance: Terminals accept wire up to AWG #12 maximum for flexible wiring options
• Philslot Combination Screws: #6-32 terminal screws accept both Phillips and slotted drivers for easy installation
• Compact Dimensions: 3.38" L x 1.37" W x 0.75" H with 3.06" mounting hole centers for straightforward panel mounting
• Close Terminal Spacing: 7/16" center spacing with 0.353" distance between barriers keeps the footprint minimal
• Wide Temperature Range: Rated from -40°F (-40°C) minimum to 302°F (150°C) maximum for harsh environment use
• Easy Mounting: Mounts securely with standard #6 screws

The Pollak 52-271 terminal block is a reliable solution for organizing and distributing power across multiple circuits in heavy-duty and commercial electrical systems.
