HAZET 40161 1-7/8 in. Trailer Hitch Ball 2000 lb. Chrome

The CURT 40161 is a 1-7/8-inch chrome trailer hitch ball rated for up to 2,000 lbs. gross trailer weight (GTW), making it well-suited for towing utility trailers, boat trailers, campers, and smaller livestock haulers with a Class 1 or Class 2 hitch setup.

Constructed from high-strength steel with a protective nickel-chrome finish, this hitch ball is built to resist corrosion and everyday wear. The fine-threaded shank provides enhanced holding strength at the ball mount, and the ball installs with the included zinc-plated hex nut and helical lock washer for a secure, reliable connection.

Key Specifications:

• Ball diameter: 1-7/8 in.
• Shank diameter: 3/4 in.
• Shank length: 1-5/8 in.
• Gross trailer weight (GTW) capacity: 2,000 lbs.
• Rise: 0 in.
• Finish: Nickel-chrome
• Includes zinc-plated hex nut and helical lock washer

Key Features:

• High-strength steel construction for long-lasting durability
• Fine-threaded shank for improved torque and holding power (160 lb.-ft. torque required)
• Chrome finish protects against rust and corrosion
• Tested and certified to meet U.S. VESC V-5 safety specifications
• Compatible with Class 1 and Class 2 trailer hitches and ball mounts
• Mounting platform must be at least 3/8 in. thick; hole size must not exceed 1/16 in. larger than the threaded shank diameter

This trailer hitch ball ships packaged with all necessary hardware for installation. Always verify that the lowest-rated component in your towing system meets or exceeds your intended load before towing.
