Ocean Accessories C3-803 Push-to-Close Grabber Catch Latch 13N Black Plastic

The Ocean Accessories C3-803 is a concealed push-to-close grabber catch latch designed to provide a reliable extra degree of closure force on doors, cabinet panels, and compartment covers. Constructed from durable PC/ABS plastic in a black finish, this latch features a spring-loaded over-center latching mechanism that engages automatically when the door is pushed closed — no handles or knobs required.

The included blue spring delivers a consistent 13N (approximately 3 lbf) pull-up force, making it ideal for lightweight doors and panels in marine, RV, automotive, and industrial applications where a clean, low-profile appearance is desired. The side-mount design allows for concealed installation using rivet or screw (through-hole) mounting.

Key Features:

• Push-to-close concealed grabber catch — no external handle needed
• 13N (3 lbf) pull-up force with blue spring
• PC/ABS plastic construction with black finish
• Side-mount design with rivet or screw (through-hole) mounting
• Spring-loaded over-center latching mechanism
• Each assembly includes catch and keeper
• Operating temperature range: -30°C (-20°F) to 60°C (140°F)
• Flammability rating: UL94-HB
• Compact dimensions: 1.1" L x 0.54" W x 1.06" H

This latch is sold as a single unit and is a direct cross-reference to the Southco C3-803. It is well-suited for use in boats, RVs, campers, motorhomes, and cabinetry where a discreet, self-latching solution is needed.
