Icom OPC-2338 14-Pin USB Programming and Data Transfer Cable

The Icom OPC-2338 is a genuine 14-pin USB programming and data cable designed for PC-to-radio configuration of compatible Icom digital portable radios. It connects directly to the radio's 14-pin accessory port and provides a reliable interface for cloning, channel programming, and firmware updates using Icom's programming software.

In addition to programming functionality, the OPC-2338 supports Type-C NXDN Transparent Data Transfer, allowing the radio to be used as a data modem for peripheral equipment in the field — ideal for IDAS and NXDN digital network deployments.

Key Features:

• 14-pin connector interfaces directly with the radio's accessory port
• USB connection to PC (compatible with USB 1.1 and 2.0 ports)
• Supports full-duplex serial communication at up to 115,200 bps data transfer speed
• Enables NXDN Transparent Data Transfer (Type-C)
• RTS and CTS pins support data modes
• Compatible with Microsoft Windows 10/8.1 (32/64-bit)
• Operating temperature range: 0°C to +60°C (32°F to 140°F)
• Cable length: approximately 9.8 inches (250 mm)
• Backed by Icom's 1-year manufacturer's warranty
• Replaces OPC-1862

Note: Programming software is sold separately. USB drivers for the OPC-2338 (without the "-1" suffix) are not compatible with OPC-2338-1 drivers.
