Quick FASP3482X02CA00 Bryan CT IP66 LED Recessed Downlight 2W Warm White Stainless Steel

The Quick Bryan CT is a 2W IP66-rated recessed power LED downlight designed for marine and demanding interior environments. It features a 72mm round trim crafted from AISI 316 stainless steel with a frosted lens for a clean, refined appearance. The "CT" designation denotes an integrated capacitive touch switch with built-in dimming capability, allowing effortless on/off and brightness control without mechanical switches.

With a wide 10–30V DC input range, this downlight is compatible with both 12V and 24V electrical systems. The IP66 protection rating makes it suitable for installation in wet or exposed areas, including heads, cockpit overheads, and exterior cabin applications. All Quick lights are two-wire dimmable, simplifying wiring and integration with existing dimmer systems.

Key Features:

• IP66 waterproof rating — suitable for wet and exposed marine environments
• AISI 316 marine-grade stainless steel frame with frosted lens
• Integrated capacitive touch switch with dimming functionality
• Wide voltage input: 10–30V DC (compatible with 12V and 24V systems)
• Ultra-low recess depth of just 35/64" — ideal for thin headliners
• Rated 50,000-hour average LED lifetime
• Warm white light output (2,900–3,100°K), 130 lm, 100° beam angle
• Two-wire dimmable design
• Screw mounting for secure installation

Specifications:

• Supply Voltage: 9–32V DC
• Power Consumption: 2W
• Current Consumption: 0.09A @ 24V
• IP Rating: IP66
• Frame Diameter: 2-53/64" (72mm)
• Recess Depth: 35/64"
• Cutout / Hole Size: 2-1/8"
• Mounting: Screws
• Color Temperature: 2,900–3,100°K (Warm White)
• Luminous Flux: 130 lm
• Beam Angle: 100°
• Average Lifetime: 50,000 hours
• Frame Material: AISI 316 Stainless Steel
