Dependable bilge pumps for commercial and recreational use.
Designed to meet and exceed the tough demands of commercial and recreational duty, these pumps feature a 12-pole motor with double ball bearings for extended service life. Impellers are carefully designed to maximize head and flow. 2200 and 4000 GPH models incorporate a mechanical seal design that eliminates shaft wear. All models feature snap-in bases that can be easily removed to clear debris. Outlet port check valve included for optional use.
Key Features
- Double ball-bearing motors for extended service life
- Snap-in base allows easy removal for clearing of debris
- Outlet port check valve included for optional use
Specifications
- Type: Submersible centrifugal electric bilge pump
- Port Sizes: 1-1/8"–2"
- Built-In Switch: No
- Material: Thermoplastic body, stainless-steel shaft
- Warranty: Three years
| Capacity | Amperage | Port Dia. | Dimensions |
|---|
| 1600gph | 7A @ 12V DC | 1 1/8" & 1 1/4" | 5 7/8"H x 4 1/4"dia. |
| 2200gph | 7.5A @ 12V DC | 1 1/8" & 1 1/4" | 7"H x 4 1/4"dia. |
| 4000gph | 19.5A @ 12V DC | 1 1/2" & 2" | 8 1/2"H x 4 13/16"dia. |
More Information
For installation instructions, see the .
