Maxwell RC8812V RC Series Vertical Windlass 12V 1000W, 1320 Lb. Max Pull

The Maxwell RC8812V RC Series vertical windlass is a 12 VDC, 1000 watt anchor windlass with a vertical drum and a below-deck motor. It pulls up to 1320 lbs. and handles 5/16" chain or 9/16" rope, making it a good fit for boaters who want a low-profile windlass on the foredeck.

Key Specifications:

• Maximum pull: 1320 lbs.
• Chain: 5/16" (8 mm), retrieved at 105 ft/min
• Rope: 9/16" (14 mm) three-strand or 8-plait, retrieved at 92 ft/min
• Voltage: 12 VDC
• Motor: 1000 watt, mounted below deck

Features:

• Rope/chain gypsy (chainwheel) accommodates a range of chain pitch differences within the specified chain sizes
• Works with all-chain rodes as well as rope/chain combinations
• Built from marine grade 316 stainless steel
• Heavy duty stainless steel pressure arm with a pre-loaded stainless steel spring helps grip the rope/chain splice and maintain control pressure
• Large through-deck hawse pipe throat for easy entry of the rode into and out of the anchor locker
• Cone-type clutch/brake allows manual free-fall anchoring
• Manual override using the emergency crank handle
• Sealed oil bath and marine grade hard anodised alloy gearbox with a precision worm and worm wheel drive
• Two-piece installation allows easy retrofitting without disassembling the windlass
• Spacer tube design suits virtually any deck thickness, with multiple mounting positions and a self-aligning gearbox
• Top works can be fully disassembled using the supplied handle, a screwdriver and an Allen key

Included: manual crank handle, circuit breaker, and up/down switch.

Anchor rode is sold separately.
