The Attwood Marine SL11-10-1 is a Ni-Slide Series gas spring designed to lift, open, hold, and lower hatches, lids, covers, and doors with smooth, controlled operation. Part of Attwood's SpringLift line, this black OEM gas spring delivers 10 pounds of output force and is ideal for marine, RV, and light-duty automotive applications.
Key Specifications:
- Extended Length: 7.5 inches
- Compressed Length: 5.25 inches
- Stroke: 2.25 inches
- Output Force: 10 pounds
- Rod Diameter: 6mm (1/4 inch)
- Cylinder Diameter: 15mm (5/8 inch)
- End Fittings: 10mm ball socket type (3/8 inch)
- Dimensions: 7.75" L x 0.65" W x 0.65" H
Environmentally Friendly Design:
Attwood Ni-Slide gas springs are manufactured with biodegradable, non-hazardous water grade oil (WGK), making them the marine industry's most environmentally friendly gas springs. The special Ni-Slide rod coating provides excellent corrosion resistance for use in saltwater environments.
Quality and Durability:
All Attwood gas springs pass rigorous ASTM B117 salt spray testing and a demanding 30,000 cycle lifecycle test, ensuring reliable performance in harsh marine conditions. The 6mm x 15mm configuration is suitable for lightweight to standard applications.
Versatile Applications:
While designed primarily for marine use, these gas springs are also suitable for industrial, agricultural, RV, and other applications requiring smooth, reliable lifting assistance. The 10mm composite head socket fittings are compatible with standard ball stud mounting brackets (sold separately).
