NewMar PT-24-60W 24V 60 Amp 3-Bank Marine Battery Charger

The NewMar PT-24-60W is a professional-grade 24-volt marine battery charger designed for workboats, military vessels, commercial craft, and recreational boats. This intelligent three-bank charger delivers 60 amps of total charging current with advanced three-stage charging technology that optimizes battery performance and extends service life.

Smart Three-Stage Charging:

The PT-24-60W automatically manages the complete charging cycle through bulk, absorption, and float stages. This intelligent process ensures fast battery recovery while preventing overcharging damage. A front-panel selector switch allows you to optimize charging parameters for gel-cell, flooded lead-acid, or AGM battery types, delivering the precise voltage profile each chemistry requires.

Key Features:

• 60-amp total output distributed across three isolated banks
• Adjustable charging profiles for gel-cell, flooded lead-acid, and AGM batteries
• Integrated ammeter displays total output current
• Compatible with battery banks from 120 to 600 amp-hours
• Optional temperature compensation sensor adjusts voltage based on ambient temperature
• Current limiting protection prevents damage from overload conditions
• Functions as a power supply without batteries connected
• ABS type approval for marine battery charging applications
• Compatible with PT-MCU for enhanced monitoring and control

Marine-Grade Construction:

Built for harsh marine environments, this charger features a rugged stainless steel enclosure with durable white powder coat finish. Internal circuitry is polyurethane coated for maximum corrosion resistance. Forced air cooling and thermal protection ensure reliable operation in ambient temperatures from -20°C to +50°C. An optional drip shield provides additional protection from water intrusion.

Technical Specifications:

• Input: 207-253 VAC, 50-60 Hz, 13 amps at 230 VAC
• Output: 24V DC, 60 amps maximum across 3 isolated banks
• Gel-cell mode: 28.0 VDC charge, 27.2 VDC float
• Flooded/AGM mode: 28.4 VDC charge, 26.8 VDC float
• Dimensions: 17.5" H x 12" W x 7.2" D (add 2" height and 1" depth with drip shield)
• Weight: 24.1 lbs
• Certifications: UL 1950, USCG CFR 183.410 ignition protected, EN 60335-1, CE marked, ABS approved

This charger is designed for permanent installation and includes current limiting, thermal protection, and forced air cooling for safe, reliable operation. The optional TP temperature sensor and PT-MCU remote monitoring system are sold separately.
