CMC 65301 High Speed Hydraulic Jack Plate with Gauge 5-1/2" Setback

The CMC 65301 PL-65HS High Speed Hydraulic Power-Lift is a premium transom jack plate designed for outboard motors up to V-6 300 HP. This high-speed model operates twice as fast as standard PL-65 models, raising your motor in approximately 8 seconds with a full stroke, making it ideal for anglers who need quick positioning adjustments on the water.

Key Features:

• High-speed hydraulic actuator with 7,853 pounds of thrust capacity
• 5-1/2 inch setback for optimal motor positioning
• 5 inches of vertical travel for precise depth adjustment
• Built-in gauge for easy position monitoring
• Constructed from 6061-T6 alloy aluminum extrusions with stainless steel fasteners
• No welds or castings that could fail under stress
• Self-contained, waterproof 12-volt DC hydraulic system
• Motor bracket provides 1.5 inches of horizontal adjustment
• Transom bracket features 1.5 inches of adjustment capability

Design Advantages:

• Hydraulic actuator mounted inside the structure yet fully accessible without engine removal
• No external hoses, pumps, or reservoirs needed inside the boat
• Self-contained fluid reservoir eliminates hydraulic plumbing complexity
• Permanent magnet motor delivers consistent power and torque
• Patented roller design reduces friction and prevents binding
• 100% non-ferrous construction resists saltwater and freshwater corrosion

This jack plate is suitable for both freshwater and saltwater environments and is rated specifically for V-6 motors and smaller. The system can lift motors even at full throttle, providing reliable performance when you need it most. Mounting hardware is included for straightforward installation.
