Analytic Systems VCH10W-24 Waterproof IP66 DC-DC Converter 10A 24V Output

The Analytic Systems VCH10W-24 is a ruggedized step-down DC-DC voltage converter designed for harsh marine, industrial, and mobile applications. This waterproof converter delivers a regulated 24V output at up to 10 amps from input voltages ranging from 30-80V DC, all within an IP66-rated watertight and EMC-shielded enclosure.

Advanced Design and Protection:

Built with high-frequency surface mount technology, the VCH10W-24 achieves over 92% efficiency while maintaining exceptional reliability in demanding environments. The converter features comprehensive protection including reverse input protection, output current limiting, and output over-voltage protection. The unit operates reliably in temperatures from -40°C to +55°C and meets MIL-STD-461F for radiated and conducted emissions, with design compliance to MIL-STD-810G for shock and vibration.

Key Features:

• IP66 waterproof rating with O-ring sealed and EMC gasketed enclosure
• Input voltage range: 30-80V DC
• Output: 24V DC at 10A (240W maximum)
• High efficiency: greater than 92%
• Deutsch connector with pigtail input/output cable
• LED indicators for 'Output ON' and 'Overload' status
• Wide operating temperature: -40°C to +55°C
• Reverse polarity, current limiting, and over-voltage protection
• Built-in paralleling diodes for multiple unit configurations
• Compact, ruggedized design for easy mounting
• Two-year parts and labor warranty

Ideal for marine electronics, emergency vehicles, military equipment, and any application requiring reliable DC power conversion in extreme conditions.
