Harken 3274 Single Bolt-Down Fairlead 12mm Anodized Aluminum

The Harken 3274 is a single bolt-down fairlead designed for use as a shallow-angle line deflector on sailboats and powerboats ranging from 6 to 15 meters (20 to 50 feet) in length. Its low-profile, deck-mounted design keeps lines running cleanly and efficiently across the deck surface.

Constructed from 6061-T6 hard lube-anodized aluminum, this fairlead delivers excellent corrosion resistance and long-term durability in marine environments while keeping weight to a minimum. The smooth surfaces and radiused 12mm center hole protect lines from premature wear and chafe, extending the life of your running rigging.

Key Features:

• Single bolt-down design for secure, permanent deck mounting
• 6061-T6 hard lube-anodized aluminum construction for corrosion resistance and weight savings
• 12mm (15/32 in) center hole diameter accommodates lines up to 10mm (3/8 in)
• Smooth, radiused center hole minimizes line wear and chafe
• Maximum working load: 2,000 lb (908 kg)
• Breaking load: 4,000 lb (1,816 kg)
• Requires 1/4 in (6mm) socket head fasteners
• Suitable for boats 20–50 ft (6–15 m)

Specifications:

• Length: 1-7/8 in (48 mm)
• Width: 11/16 in (18 mm)
• Height: 1-1/8 in (28.2 mm)
• Weight: 0.99 oz (28 g)
• Center Hole Diameter: 12mm (15/32 in)
• Maximum Line Diameter: 10mm (3/8 in)

The Harken 3274 is an ideal solution for cleanly routing control lines, halyards, or sheets across the deck with minimal friction and maximum protection for your running rigging.
