CMC 61012 ML-65 Manual Jack Plate 10 Inch Setback

The CMC 61012 ML-65 Manual Jack Plate is a high-quality outboard motor mounting system that provides 10 inches of setback from the transom and 5 inches of vertical travel adjustment. This manual jack plate allows boaters to optimize motor height and positioning for improved performance, speed, and fuel efficiency in various water conditions.

Construction and Materials:

• Constructed from 1/2 inch thick 6061 T6 extruded aluminum alloy for exceptional strength and corrosion resistance
• Stainless steel fasteners throughout for maximum durability in marine environments
• One-piece design for superior structural integrity
• Aluminum-bronze alloy rollers for smooth, reliable vertical adjustment

Key Features and Specifications:

• 10 inch setback from transom for improved weight distribution and performance
• 5 inches of vertical adjustment range for precise motor height tuning
• Centrally located all-thread stainless steel adjustment screw ensures uniform lift and positive alignment
• Rated for outboard motors up to 300 HP V-6 applications
• Adjustable from top or bottom for convenient operation
• Fits standard B.I.A. bolt pattern without modifications to boat or motor
• Includes all mounting hardware for straightforward installation

Benefits:

• Optimizes boat performance by allowing proper motor height adjustment
• Improves fuel efficiency through better trim positioning
• Enhances shallow water operation capability
• Reduces propeller ventilation and improves hole shot
• Increases top speed potential through optimal motor placement
• No drilling or permanent modifications required for installation

The CMC ML-65 series has been the industry standard in manual jack plate technology for decades, trusted by thousands of boaters for its proven reliability and performance. This manual jack plate can also be converted to a 5.5 inch setback configuration if needed, providing flexibility for different applications.
