The Xantrex Freedom XC PRO Marine 2000 is a professional-grade true sine wave inverter/charger designed specifically for marine applications. Supporting CANbus NMEA 2000 protocol, this versatile power solution delivers 2000 watts of continuous power with a built-in 100 amp multi-stage battery charger and automatic transfer switch in a compact, lightweight package.
Advanced Marine Integration
The Freedom XC PRO Marine supports seamless integration with third-party monitoring and control display panels that use NMEA 2000, or J-1939 communication protocols. Monitor and configure your Freedom X inverter using the optional Bluetooth remote panel (# 808-0817-02). The built-in USB port allows for easy firmware upgrades and OEM-configured settings.
Reliable Power in Any Climate
It cranks out full output in invert or charge mode from -4°F (-20°C) – 104°F (40°C), ensuring dependable operation in all marine environments. The extended surge rating enables compressor loads such as an A/C or a fridge to start reliably, surging to 2X continuous power for 5 seconds to handle demanding motor loads.
Key Inverter Features:
- True Sine Wave Output: Clean power for sensitive electronics and motor-driven equipment
- Wide 10-18 VDC Input Range: Compatible with high voltage alternators found on modern marine electrical systems
- Ignition Control: Turn the inverter on/off via 12 VDC signal to minimize battery drain when not in use
- Built-in 30A Transfer Relay: Automatic switching between inverter power and shore/generator power (24A continuous, 30A surge)
- Programmable AC Under-Voltage Shutdown (85-110VAC): Ideal for operation under weak shore power or generator input
Advanced Battery Charging:
- Power Factor Corrected Multi-Stage Charging: Efficient 100 amp charging reduces shore power demand, freeing up AC capacity for other appliances
- Universal Battery Compatibility: Configurable 3-stage temperature compensated charging algorithm supports flooded, gel, AGM, and lithium-ion batteries up to 18V
- Dead Battery Recovery: Charges batteries down to 0 VDC
- Battery Equalization: Maximizes flooded battery lifespan
- Power Share Technology: Prioritizes AC loads by reducing charge current to prevent tripping shore power breakers
Specifications:
- Continuous Output Power: 2000W
- Battery Charger Output: 100A
- Input Voltage: 12 VDC nominal (10-18 VDC range)
- Output Voltage: 120 VAC, 60 Hz
- Transfer Relay Rating: 24A continuous, 30A surge
- Operating Temperature: -4°F to 140°F (-20°C to 60°C)
- Certifications: UL458, CSA 107.1, ABYC E-11, A-31, FCC Part 15 Class B
What's Included:
- Freedom XC PRO Marine 2000 Inverter/Charger
- Plastic bushings for large DC cables
- Pre-installed DC ground enclosure lug
- Two AC knockout hole plugs
The Xantrex 818-2015 Freedom XC PRO Marine represents the pinnacle of marine inverter/charger technology, offering unmatched configurability, reliable performance, and seamless integration with modern boat electrical systems.
