NewMar BX1 Splashproof Junction Box 2" x 2" Marine Electrical

The NewMar BX1 junction box provides secure, protected wiring connections for marine applications in wheelhouses, below decks, and engine rooms. This compact splashproof enclosure features rugged cast aluminum construction with a white enamel finish and IP54 rating for reliable protection against water spray and splash.

Key Features:

• IP54 rated splashproof protection for harsh marine environments
• Rugged cast aluminum construction with durable white enamel finish
• Metal enclosure reduces electrical interference and provides EMI shielding
• Multiple grommeted cable entries for easy wiring access and strain relief
• Includes high-quality connector strip with compression fittings - no terminals required
• Compact 2" x 2" footprint ideal for space-limited installations

Technical Specifications:

• Connector Strips: 1 strip with 6 positions
• Maximum Wire Gauge: 16 AWG
• Maximum Current: 6 amps per position
• Cable Entries: 2 grommeted openings
• Cable Diameter: 0.25 inches (6.35mm)
• Box Dimensions: 2" x 2" x 1.2" (5.1 x 5.1 x 3.1 cm)

The BX1 junction box simplifies marine electrical installations with its tool-free compression wire fittings and protected terminal design, ensuring reliable connections in demanding marine conditions.
