NewMar PT40U 12V 40 Amp Smart Battery Charger 3-Bank Marine

The NewMar PT40U is a professional-grade 12-volt, 40-amp smart battery charger designed specifically for marine applications including workboats, military vessels, commercial craft, and recreational boats. This intelligent charger delivers a three-stage charging process—bulk, absorption, and float—that ensures fast battery recovery while maximizing performance and extending battery life.

Key Features:

• 40-amp output with three isolated charging banks for independent battery management
• Adjustable battery type selector for gel-cell, flooded lead-acid, or AGM batteries with optimized charge profiles
• Universal input voltage (90-264 VAC, 50-60 Hz) with excellent power factor (.98 @ 115V)
• Rugged stainless steel case with white powder coat finish and polyurethane-coated internal circuitry for maximum corrosion resistance
• Can function as a regulated power supply to run loads directly without battery connection
• Current limiting protection prevents damage from overloading
• Built-in ammeter displays total output current across all banks
• Optional temperature compensation sensor (TCS-12/24) adjusts output voltage based on ambient battery temperature
• USCG ignition protected (CFR 183.410) and ABS-type approved for marine battery charging

Technical Specifications:

• Input: 90-264 VAC, 50-60 Hz (6.8A @ 115V, 3.4A @ 230V)
• Output: 40 amps maximum across 3 banks
• Recommended battery capacity: 80-400 amp-hours
• Output voltages: Gel-Cell mode (14.0V charge/13.6V float), Flooded/AGM mode (14.2V charge/13.4V float)
• Operating temperature: -20°C to +70°C (derated linearly from 100% @ 50°C to 50% @ 70°C)
• Dimensions: 13.85" H x 9.5" W x 4.8" D (add 0.75" height and 1.35" depth with optional drip shield)
• Weight: 11 lbs

Optional Accessories:

• Remote panel (EVM-12-2) for monitoring charger status and battery readiness of two banks
• Temperature compensation sensor (TCS-12/24) with 25-foot cable (40-foot cable available)
• Drip shield for enhanced protection in harsh marine environments

The PT40U's clean, well-regulated output and forced air cooling system ensure reliable operation in demanding marine conditions. This charger meets strict marine compliance standards including CE marking and ABS certification for vessels under 90 meters.
