Dexter Marine Products K23-181-00 12" x 2" Electric Brake Assembly Right Hand 7000 lbs

The Dexter K23-181-00 is a complete 12-inch by 2-inch electric brake assembly designed for right-hand (passenger side) installation on trailer axles with a maximum capacity of 7,000 lbs per pair (3,500 lbs individual capacity). This drum-style electric brake assembly provides reliable stopping power for utility trailers, RV trailers, and boat trailers equipped with electric brake systems.

Key Features:

• Complete ready-to-install electric brake assembly with backing plate, brake shoes, magnets, actuating lever, adjusting screw, and spring hardware
• 12" x 2" brake shoe size for compatibility with standard 12-inch brake drums
• Right-hand configuration for passenger side mounting
• Manual shoe adjustment design allows fine-tuning via brake controller
• 5-hole mounting flange accepts standard 3/8" bolts (mounting hardware not included)
• Non-polarized black wire magnet for electromagnetic actuation
• Fits wheel sizes from 14.5 to 16 inches
• CSA approved and manufactured in the USA

This assembly mounts to a 5-hole axle brake flange and requires a brake controller for operation. The electric brake system offers more responsive control compared to hydraulic systems, with minimal lag time from brake pedal actuation to trailer brake engagement. Includes brake assembly (023-181-00) and installation instructions. Not suitable for marine applications despite the "Marine Products" brand designation.

Replacement Components: Brake shoes K71-127-00, Magnet K71-125-00. Cross-references: 023-181-00, 023-358-00, 023-360-00, Sirco K23-181, Automann 160.23181.
