The Simrad HALO 200X Radar Pedestal is a high-performance 50-watt pulse compression radar pedestal designed for marine navigation systems. This pedestal-only unit is compatible with HALO 2000 series 3-foot, 4-foot, and 6-foot open array antennas, providing the foundation for a complete radar system when paired with a compatible antenna array, cable, and power supply.
Advanced Pulse Compression Technology:
The HALO 200X utilizes solid-state pulse compression technology that delivers 50 watts of power, equivalent to a 12 kW magnetron radar. This provides exceptional range capabilities from 6 meters (20 feet) out to 72 nautical miles with superior target resolution and clarity. The system features beam sharpening technology for enhanced separation between small or distant targets, and advanced digital signal processing that helps eliminate sea clutter for clearer target identification.
Key Features:
- 50W pulse compression radar pedestal for open array systems
- Low-profile aerodynamic design with same footprint as predecessor models for easy upgrades
- High-speed 48 RPM rotational speed for better tracking of fast-moving targets
- Instant readiness from standby mode, 16-25 seconds from cold start
- Compatible with 3-foot, 4-foot, and 6-foot HALO antenna arrays
- Solid-state electronics with brushless motor for virtually maintenance-free operation
- Low-power pulsed transmissions safe for operation in harbors and marinas
- Sealed gearbox and helical geartrain for quiet, reliable operation
System Compatibility:
The HALO 200X pedestal integrates seamlessly with Simrad NSS, NSX, NSO, and GO series chartplotters. When combined with a compatible open array antenna, RI-50 power supply (000-15757-001), and radar cable, it creates a complete HALO 2000 series radar system capable of simultaneous dual range operation, ZoneTrack target tracking, VelocityTrack Doppler technology, and preset modes including Harbour, Offshore, Weather, and Bird modes.
Note: This is the pedestal unit only. Antenna array, power supply, and cable are sold separately and required for a complete radar system.
