Sea-Dog Line 8014302 14/3 AWG Flat Triplex Marine Wire White/Green/Black 100ft

The Sea-Dog Marine Wire™ 14/3 AWG Flat Triplex Cable is a premium 3-conductor boat wire engineered for reliable performance in demanding marine electrical installations. This 100-foot spool features tinned copper stranded conductors sheathed in a flat, flexible PVC jacket — making it an ideal choice for AC wiring runs aboard recreational and commercial vessels.

The conductors follow standard ABYC color coding: black (hot), white (neutral), and green (ground), simplifying AC circuit installations. The flat triplex construction bundles all three conductors into a single cable, streamlining routing when all three wires must run to the same location. The outer jacket can be stripped back to separate individual leads at termination points.

Key Features:

• Gauge & Configuration: 14 AWG, 3-conductor flat triplex construction
• Conductor Material: Annealed, finely stranded tinned copper for superior corrosion resistance and flexibility
• Voltage Rating: 600V
• Temperature Rating: 105°C dry / 75°C wet
• Oil resistant PVC outer jacket
• Color Coding: White/Green/Black — ABYC standard AC colors
• Length: 100 feet
• Certifications: UL Listed Boat Cable (UL 1426)
• Made in the U.S.A.

Sea-Dog Marine Wire™ is available in gauges ranging from 16/3 to 6/3 to accommodate a wide range of onboard AC applications. The annealed, finely stranded copper construction resists vibration fatigue and remains flexible for easy routing through tight spaces, bulkheads, and conduit runs.
