Johnson Pumps 09-24652-04 PUMProtector Universal Pump Strainer 20 Mesh Screen

The Johnson Pumps 09-24652-04 PUMProtector Universal Strainer is a 20-mesh inline pump strainer designed to protect pumps from debris and particulates that could cause damage or pass through to the system outlet. Its compact, purpose-built design makes it a reliable choice for marine, RV, and general-purpose water pump applications.

Featuring a transparent acrylic cover, the strainer allows for quick visual inspection without requiring removal. The KlickTite quick-connect port system enables fast, tool-free disconnection for cleaning or maintenance at your convenience. The 20-mesh stainless steel screen is recommended for general-purpose pump applications, making this strainer a versatile fit across a wide range of pump systems.

Key Features:

• Transparent clear acrylic cover for easy visual inspection without disassembly
• KlickTite quick-connect ports for simple, tool-free installation and removal
• Compatible with any pump manufacturer using KlickTite-style ports
• 20-mesh stainless steel screen — ideal for general-purpose pump protection
• Includes two sets of KlickTite connectors: 2x for 1/2" hose (3/8" NPT) and 2x for 3/4" hose (1/2" NPT)
• Strainer body: Polyamide 66 (black); Cover: Clear acrylic; O-rings: Silicone and EPDM
• Max liquid temperature: 120°F (50°C); Max temperature for drinking water: 85°F (30°C)

Specifications:

• Diameter: 3.15" (80 mm)
• Height: 2.35" (60 mm)
• Weight: 0.33 lbs (0.15 kg)
• Mesh Size: 20
• Connector: 2 x 1/2" hose / 3/8" NPT & 2 x 3/4" hose / 1/2" NPT

The Johnson Pumps PUMProtector strainer is engineered for long, trouble-free pump operation. Additional angled and specialty KlickTite connector styles are available by special order for custom installation configurations.
