AFI 28210 ChargePro 10A 2-Bank Marine Battery Charger 12V/24V

The AFI 28210 ChargePro is a 2 bank, 10 amp, 12/24V DC output charger with wide input voltage range (100-240V AC) designed for harsh marine and industrial environments. This microprocessor-controlled onboard battery charger delivers intelligent, fully automatic charging to keep your batteries maintained and ready.

Key Features:

• Charges flooded, AGM, and Gel batteries with precision 5-stage charging algorithm
• Sense-Send™ technology senses the power needs of each battery and sends correct charge
• Microprocessor controlled with maintenance mode to keep batteries fully charged
• Universal input voltage range: 90-265V AC 50/60Hz for worldwide compatibility
• Isolated outputs can be configured in series or parallel for higher voltage or current
• Completely sealed, epoxy filled with IP68 waterproof rating
• Tested for moisture, salt, shock and vibration in harsh marine environments
• Non-corroding housing for ultimate reliability and longevity
• ConnectCharge Plug for easy assembly to inlet with no wiring

Specifications:

• Output: 12/24V DC with 14.3V absorption charge and 13.3V float voltage per bank
• Total charging current: 10 amps (5 amps max per bank)
• Battery capacity: Group 24 through 31 (up to 120 Amp-Hours)
• AC cable: 6 ft with 18 AWG wire
• DC cable: 4 ft with 14 AWG wire and ring terminals
• 15 Amp fuse size
• Dimensions: 5.5" L x 7.8" W x 2.4" H
• Weight: 5.6 pounds

This charger meets global industry standards including UL, CE, CSA, ABYC, and California energy efficiency regulations (CEC). The same footprint as traditional Charge Pro Guest chargers makes it an ideal replacement or upgrade for existing installations.
