This low profile true sine wave inverter packs big power in a small package.
The compact, easy-to-use and easy-to-install design of the PROwatt SW 600 Inverter makes it ideal for use in commercial truck, RV and marine applications. It is designed to operate AC loads as if these loads were operating from grid/utility supplied power in household AC outlets. It also meets UL458 marine supplement. With high surge capability, the PROwatt SW 600 provides the necessary current to startup demanding electrical loads such as variable speed power tools, advanced electrical appliances and much more.
Power portable devices with USB outlet: In addition to dual GFCI AC receptacles, the PROwatt SW 600 include an innovative USB connection for providing power to most USB chargeable devices. The PROwatt SW 600 offers many safety features not found in similar inverters. When equipped with a remote control, the PROwatt SW 600 has the ability to provide automatic ignition lockout shutting down the inverter’s output when the vehicle’s ignition is not engaged.
Low Standby Current Draw: The inverter’s low standby battery demand means you don’t have to worry about excessive drain on your battery if you leave the inverter on for a few days. When the inverter is on but no power is being supplied to a load, the inverter draws less than 800 mA from the battery.low standby battery demand means you don’t have to worry about excessive drain on your battery if you leave the inverter on for a few days. When the inverter is on but no power is being supplied to a load, the inverter draws less than 800 mA from the battery.
Optional Transfer Relay 808-0915 (Model 14567903, sold separately): An easy to install 15A Inline Transfer Relay provides switching between shore-power and inverter AC source. It comes equipped with a power plug for convenient connection to the inverter GFCI and a hardwire cord for the AC input and output interface.
Optional Remote Panel 808-9001 (Model 14567911, sold separately): The Prowatt SW remote provides the convenience of a simple On/Off remote function. It also has an automatic ignition lockout feature to shut down the inverter’s output when the vehicle’s ignition or a 12V DC enable is not engaged. A 25’ remote cable is included with the remote panel.
Key Features
- Easy-to-read digital display on the front panel lets you monitor system performance at a glance; Digital display of output power and DC volts
- You can power loads directly from the dual GFCI-protected AC receptacles on the front panel
- A convenient USB port powers most modern electronic products
- Optional on/off Remote Control Panel (Model 14567911, sold separately)
- Automatic AC transfer function and hardwire through the optional Transfer Relay
- Prevents unnecessary battery drain by automatic ignition lockout when equipped with remote, thereby shutting down the inverter’s output when the vehicle’s ignition is not engaged
- Ideal for commercial trucks, boats and RVs, the PROwatt SW 600’s compact design and easy installation allow optimal performance almost anywhere you go
- Meets UL458, a safety and quality standard for mobile applications
Specifications
- Digital Display: Shows DC voltage AC output power and error codes
- Approvals: UL458 – 5th Edition, CSA 107.1-01, FCC Part 15, Class A
- AC Output Frequency: 60 ± 0.5 Hz
- AC Output Voltage Range: 104-127V AC
- USB Output: 5V / 500mA
- Continuous Capacity: 540W (4.6A)
- Surge Capacity: 1,200W (5.8A)
- Output Waveform: Pure sine wave
- Output Type: Dual GFCI and USB
- DC Input Type: Hardwire
- Input Voltage Range: 10.5-15.5V DC
- Recommended DC Fuse: 80A ANL or Class T
- Idle Current: <0.6A
- Inverter Efficiency: 90%
- Alarms: Low battery voltage shutdown, High battery voltage shutdown, AC output overload shutdown, Over temperature shutdown, Low battery voltage alarm
- Remote Available: Remote panel with 25’ remote cable 808-9001 (Model 14567911, sold separately)
- Case Size: 3 1/2"H x 8 11/16"W x 12 3/16"D
- Mounting Hardware Included/Required: Mounting screws (4) size #10 (sold separately)
- Warranty: Two years
What’s in the box
- PROwatt SW Inverter unit, Owner’s Guide
