Uflex 42010R Power A Mark II Single Lever Electronic Control with Trim

The Uflex 42010R Power A Mark II is an advanced electronic engine control system designed for single-engine marine applications with integrated trim functionality. This single-lever, dual-function control provides fingertip operation of throttle and shift functions through reliable digital data transmission, compatible with mechanically controlled, electronic, and electro-hydraulic gas and diesel inboards, sterndrives, and outboards.

Key Features:

• Dock Assist: Reduces throttle sensitivity for easier dockside maneuvering and precise low-speed control
• RPM Synchronization: Minimizes engine vibration and improves fuel economy
• High Idle Function: Increases RPM for cold engine operations when needed
• Programmable Trolling Valve Control: Adjustable for precise low-speed fishing applications
• Neutral Warm Up: Allows engine warm-up in neutral position
• Multi-Station Capability: Control up to 2 engines from up to 4 different control stations
• Touch Pad Programming: Intuitive Control Unit Display provides easy setup, tuning, and diagnostics
• Audible and Visual Alerts: Real-time status information and diagnostic failure alarms with readable messages

Technical Specifications:

• Power supply: 9-32V DC
• Operating temperature range: -25°C to +75°C (-13°F to +167°F)
• Electronic throttle outputs: Voltage (0-5V and 0-2.5V), PWM (0-100%, 200Hz to 1kHz), Current (4-10mA)
• Digital throttle output: SAE J1939 and NMEA 2000 compatible
• Trolling valve output: Voltage (0-5V), PWM (0-100%, 100Hz to 1kHz), Current (4-20mA)
• Electric shift control: 2 or 3 ON/OFF or proportional solenoids with fully adjustable shift delays

Safety Features:

• Start-in-gear protection prevents engine starting with shifted gear
• Proportional shift delays for smooth gear transitions
• Programmable working parameters for customized operation
• Meets CEI EN 60945, UNI-EN ISO 11547 standards
• EMC certified with CE Mark

The ergonomically designed Power A Mark II control is suitable for sport boats, yachts, and commercial marine applications. Its modular design features simple-to-install components that can replace mechanical controls on fully mechanical engines, fully electronic engines, or hybrid systems. Compatible with major marine engine brands including Cummins, Detroit Diesel, Scania, Iveco, FPT, Lombardini, VM Motori, Yanmar, and Hyundai.

Note: Power A Mark II electronic system actuators cannot be installed in areas where ignition-proof devices are required.
