Intellian s6HD is a digital marine satellite antenna system specially designed for the DIRECTV HD services for all types of vessels (anchored or in transit) to automatically identify, track and capture satellite signals from the Digital Video Broadcasting (DVB: the international standard for digital TV transmissions) compatible satellites.
Intellian s6HD is a dual-band 2-axis marine satellite antenna system which is capable of receiving three DIRECTV satellite signals simultaneously. Receiving signals from one DIRECTV 101°W Ku-band satellite and two DIRECTV 99°W and DIRECTV 103°W Ka-band satellites at the same time, you can simultaneously watch all DIRECTV channels no matter which satellite your target program is coming from. This also enables the channel guide data to remain constantly up to date.
Using a simple connection to the antenna, the Intellian s6HD with a Single Wiring Multi-switch (SWM) enables 16 receivers to view all DIRECTV channels with the possibility to upgrade to 32 SWM Receivers or DVRs. The s6HD is also compatible with general Ku-band receivers such as DISH Network, Bell TV and DIRECTV local channel programming services.
Simultaneous reception of three DIRECTV satellites: Receives HDTV channels from three primary DIRECTV Ka-band and Ku-band satellites located at 99°W, 101°W and 103°W. No delay time or changing the satellite signal. You can simultaneously watch every DIRECTV channel.
Multi-band alignment control systems: Keep the multi-feed LNB aligned with the three DIRECTV satellites at sea even during harsh marine environment or high-speed cruising.
Non-primary DIRECTV service receptions: Capable of receiving DIRECTV local channels broadcast from the two DIRECTV Ku-band satellites located 110°W and 119°W as well as Dish Network and Bell TV services
- Plug and play, DIRECTV capable - easy operation
- Single cable from the antenna to ACU for simple installation
- Built-in SWM (Single Wiring Multi-switch) and two 8-way splitters in the default package enables 16-receiver connections as standard
- Expandable up to 32 receivers and beyond
- Fully capable of supporting DVR receivers
Specifications
- Dish Diameter: 24"
- Antenna Weight: 47.8lb.
- Dome Dimensions: 27 1/2" dia. x 28 5/16"H
- Minimum ERP: 74dbW
- Elevation Range: +5° to +90°
- Ship’s Motion: Roll 25°, Pitch 15°
- RF Output: Quad output
- Warranty: Two-year parts, one-year labor
