The Balmar XT-VT-170-K6-KIT is a complete high-output charging system designed for marine applications requiring superior power delivery and intelligent charging management. This comprehensive kit includes the XT-VT-170-K6 alternator, MC-618 MaxCharge multi-stage voltage regulator with wiring harness, and alternator and battery temperature sensors with mounting hardware.
XT Series Alternator Specifications:
- Output: 170 amps at 12 volts
- Mount Style: Vortec (Delco 9Si style) for GM-block engines
- Pulley Type: K6 serpentine pulley configuration
- Ground: Case ground design
- Superior idle performance: delivers up to 128 amps at idle speeds
- Enhanced cooling with high-reliability bearings and robust rectifier diodes
- Typical applications: GM 5.0L, 5.7L, and 6.2L gasoline engines
MC-618 MaxCharge Regulator Features:
- Intelligent multi-stage voltage regulation with 9 selectable battery programs
- Compatible battery types: standard flooded, deep-cycle flooded, gel, AGM, spiral-wound AGM, LiFePO4, and Carbon Foam AGM
- Bluetooth connectivity for smartphone app programming and monitoring
- Integrates with Balmar SG200 Battery Monitor for advanced system visibility
- 15 amp maximum field current capacity
- Advanced temperature sensing and compensation for both alternator and battery
- Belt Load Manager function to reduce stress during startup
- Digital LED display for easy status monitoring
Complete System Benefits:
This kit transforms your charging system into an intelligent power management solution optimized for demanding marine environments. The multi-stage regulation ensures faster, more complete battery charging while protecting against overcharging. The temperature sensors automatically adjust charging parameters based on real-time conditions, extending battery life and maximizing performance. The XT Series alternator's superior idle output makes it ideal for vessels with high electrical loads at low engine speeds, including sailboats, fishing vessels, and workboats.
For applications requiring an isolated ground alternator, use XT-VT-170-K6-IG and purchase the regulator and temperature sensors separately. The system may require a Tachometer Signal Stabilizer (Part No. 15-TSS) if your existing tachometer is not adjustable. XT-Series alternators should only be used with dual vee or multi-groove serpentine belt configurations.
