TRUECharge2 Battery chargers lead the industry with a small footprint and ultra-compact design. Designed for marine and commercial applications worldwide, the new TRUECharge2 10 Amps charger is the latest addition to the TRUECharge2 series. The charger replaces the former best-selling, first-generation TRUECharge 10TB unit and features universal auto ranging input voltage (90VAC to 265VAC, 47 to 63Hz), which can be used in most parts of the world. The TRUECharge2 10 Amps is smaller and lighter than its predecessor and can be mounted in a variety of positions. The TRUECharge2 10 Amps charger uses power factor correction to deliver a full 3-stage charge cycle. As a result, the charger requires less incoming AC power to operate at its peak efficiency, freeing up more usable AC power for onboard electronics. The TRUECharge2 10 Amps charger meets stringent safety and regulatory standards including UL1564 and UL1236.
- Microprocessor-controlled, multi-stage charging algorithms
- Charges flooded, gel, AGM or lead-calcium batteries
- Auto-ranging universal input voltage (90 to 265VAC, 47 to 63Hz) is also compatible with a generator or
- other low-quality power sources
- Power factor corrected, temperature-compensated charging
- Ability to charge healthy batteries drained to low voltage
- Mounting is possible in a variety of orientations and in areas where space is limited
- Easy access to AC and DC wiring from one side
- Tested to conform to ingress protection rating IP32 and meets UL1564, UL1236 including marine
- Weight: 3.3lb.
- Dimension: 2.7"H x 5.4"W x 8.8"L
- Temperature: 0 to 65 Deg C Operating, -40 to 80 Deg C Storage
