Parker Hannifin 500FG2 Racor Turbine Fuel Filter Water Separator 60 GPH 2 Micron

The Parker Hannifin 500FG2 is a high-performance diesel fuel filter and water separator from the renowned Racor Turbine Series. Engineered for reliable protection of diesel engines, this compact 60 GPH unit features a three-stage filtration system that effectively removes water, dirt, sand, silica, and other harmful contaminants from diesel and biodiesel fuel.

Key Features:

• 2-micron Aquabloc® filtration element for maximum water removal and particulate capture
• 60 GPH (227 LPH) maximum flow rate ideal for light to medium duty diesel applications
• Clear plastic bowl with stainless steel shield for visual inspection of water accumulation
• Compact design: 11.45" height x 4.15" width x 4.15" depth - perfect for space-restricted installations
• 3/4"-16 UNF SAE ports for easy integration into fuel systems
• Three-stage filtration removes water through coalescence into large droplets that settle in collection bowl
• Aquabloc® media is waterproof and rustproof with graduated pore structure for extended filter life
• Maximum head pressure rating of 15 PSI (1.03 bar)
• Operating temperature range: -40°F to 255°F (-40°C to 124°C)
• Uses 2010SM-OR replacement elements

This Racor Turbine assembly comes complete with a pre-loaded 2-micron filter element. Ideal for agricultural equipment, construction vehicles, power generation, light to medium duty trucks, marine applications, and other diesel-powered equipment where reliable fuel filtration is critical. The proprietary Aquabloc® filtration technology prevents costly injector damage, extends the operational life of downstream filters, and eliminates unplanned maintenance due to fuel contamination.
